KEYENCE PJ-50A PJ Expandable Area Sensor Base Unit
- Brand
- KEYENCE
- Model
- PJ-50A
- GEARWELL SKU
- GWP-000015646
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Power voltage
- 12 to 24 VDC ±10 %
- Response time
- 15 ms or less
- Control output
- NPN open collector, 100 mA max. (40 V max.)
- Enclosure rating
- IP64
- Beam axis spacing
- 40 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KEYENCE PJ-50A PJ Expandable Area Sensor Base Unit |
|---|---|
| Brand | KEYENCE |
| Model | PJ-50A |
| Category | Proximity & Photoelectric Sensors |
| Power voltage | 12 to 24 VDC ±10 % |
| Response time | 15 ms or less |
| Control output | NPN open collector, 100 mA max. (40 V max.) |
| Enclosure rating | IP64 |
| Beam axis spacing | 40 mm |
| Detectable object | Opaque, ø50 mm min. |
| Detecting distance | 5 m |
| Number of optical axes | 4 (max. 28 with PJ-55A x 12) |
