KEYENCE GT-72AP GT Contact Sensor Amplifier
- Brand
- KEYENCE
- Model
- GT-72AP
- GEARWELL SKU
- GWP-000012843
- Category
- Encoders & Position
Key specifications
- Type
- Amplifier unit, expansion unit
- Output
- PNP open collector, 50 mA max. (HIGH/GO/LOW)
- Weight
- approx. 110 g
- Display
- 6-digit 7-segment LED (red)
- Mounting
- DIN rail
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KEYENCE GT-72AP GT Contact Sensor Amplifier |
|---|---|
| Brand | KEYENCE |
| Model | GT-72AP |
| Category | Encoders & Position |
| Type | Amplifier unit, expansion unit |
| Output | PNP open collector, 50 mA max. (HIGH/GO/LOW) |
| Weight | approx. 110 g |
| Display | 6-digit 7-segment LED (red) |
| Mounting | DIN rail |
| Power voltage | 12 to 24 VDC |
| Response time | hsp (1.5 ms) to 5 s |
| Sampling rate | 2,000 times/s |
| Display resolution | 1 µm |
| Ambient temperature | -10 to +55 °C |
