KEPCO FAK24-0.7K FAK DC Power Supply
- Brand
- KEPCO
- Model
- FAK24-0.7K
- GEARWELL SKU
- GWP-000018507
- Category
- Power Supplies
Key specifications
- Weight
- approx. 1.5 kg
- Dimensions
- approx. 190 x 90 x 40 mm
- Regulation
- ±0.05% FS
- Input voltage
- 100-240 V AC
- Output current
- 0-0.7 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | KEPCO FAK24-0.7K FAK DC Power Supply |
|---|---|
| Brand | KEPCO |
| Model | FAK24-0.7K |
| Category | Power Supplies |
| Weight | approx. 1.5 kg |
| Dimensions | approx. 190 x 90 x 40 mm |
| Regulation | ±0.05% FS |
| Input voltage | 100-240 V AC |
| Output current | 0-0.7 A |
| Output voltage | 0-24 (adjustable) V DC |
| Input frequency | 50/60 Hz |
| Ripple and noise | <1 mVpp |
| Ingress protection | IP20 |
| Rated output power | 16.8 W |
| Specification note | Specifications from supplier data; please verify against the nameplate before ordering. |
| Operating temperature | -10 to +50 °C |
