JUMO 902044/20-380-1003 Screw-in RTD Temperature Probe
- Brand
- JUMO
- Model
- 902044/20-380-1003
- GEARWELL SKU
- GWP-000022209
- Category
- Pressure, Flow & Temperature
Key specifications
- Basic type
- 902044/20 = with junction box Pg9 to DIN EN 175301-803
- Protection type
- IP65
- Measuring insert
- 1003 = 1x Pt100 in two-wire circuit
- Operating temperature
- 380 = -50 to +200 °C
- Tolerance class options
- 1 Class B / 2 Class A / 3 Class AA (specify on order)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | JUMO 902044/20-380-1003 Screw-in RTD Temperature Probe |
|---|---|
| Brand | JUMO |
| Model | 902044/20-380-1003 |
| Category | Pressure, Flow & Temperature |
| Basic type | 902044/20 = with junction box Pg9 to DIN EN 175301-803 |
| Protection type | IP65 |
| Measuring insert | 1003 = 1x Pt100 in two-wire circuit |
| Operating temperature | 380 = -50 to +200 °C |
| Tolerance class options | 1 Class B / 2 Class A / 3 Class AA (specify on order) |
| Insertion length options | 50 / 100 / 150 / 200 / 250 / 500 mm ... (specify on order) |
| Protection tube diameter | 8 = Ø 8 mm |
| Protection tube material | Stainless steel 1.4571 |
| Process connection options | 102 G1/4 / 103 G3/8 / 104 G1/2 / 126 M18x1.5 / 128 M20x1.5 / 144 1/2-14 NPT (specify on order) |
