INOVANCE IT7100E IT7000 Series 10.1-inch HMI Touch Panel
- Brand
- INOVANCE
- Model
- IT7100E
- GEARWELL SKU
- GWP-000024394
- Category
- HMIs & Industrial PCs
Key specifications
- CPU
- Cortex-A8 1 GHz
- Memory
- 256 MB DDR3 / 256 MB flash
- Display
- 10.1" TFT, 1024 x 600, 24-bit colour
- Ethernet
- 1 port
- Brightness
- 350 cd/m2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | INOVANCE IT7100E IT7000 Series 10.1-inch HMI Touch Panel |
|---|---|
| Brand | INOVANCE |
| Model | IT7100E |
| Category | HMIs & Industrial PCs |
| CPU | Cortex-A8 1 GHz |
| Memory | 256 MB DDR3 / 256 MB flash |
| Display | 10.1" TFT, 1024 x 600, 24-bit colour |
| Ethernet | 1 port |
| Brightness | 350 cd/m2 |
| Protection | front IP65, rear IP20 |
| Product code | 01450036 |
| Serial ports | COM1 RS422/RS485, COM2 RS232, COM3 RS485 |
| Input voltage | 24 V DC +/-20% |
| Rated input current | 300 mA |
