INOVANCE IS620PT5R41-C IS620P AC Servo Drive 5.4 A
- Brand
- INOVANCE
- Model
- IS620PT5R41-C
- GEARWELL SKU
- GWP-000024889
- Category
- Servo Systems
Key specifications
- Series
- IS620P servo drive (pulse/analog)
- Frame size
- SIZE-C
- Input supply
- Three-phase 380-440 Vac, 50/60 Hz
- Code suffix "1"
- as collected; the official IS620 model key has the installation letter "I" (base mount) at this position
- Voltage class
- T: 400 Vac
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | INOVANCE IS620PT5R41-C IS620P AC Servo Drive 5.4 A |
|---|---|
| Brand | INOVANCE |
| Model | IS620PT5R41-C |
| Category | Servo Systems |
| Series | IS620P servo drive (pulse/analog) |
| Frame size | SIZE-C |
| Input supply | Three-phase 380-440 Vac, 50/60 Hz |
| Code suffix "1" | as collected; the official IS620 model key has the installation letter "I" (base mount) at this position |
| Voltage class | T: 400 Vac |
| Product type code | P: Pulse/Analog |
| Rated output current | 5.4 A |
| Maximum output current | 14.0 A |
| Customized function code "C" | CANlink |
