INOVANCE IS580T080-R1 IS580 Electro-Hydraulic Servo Drive 45 kW
- Brand
- INOVANCE
- Model
- IS580T080-R1
- GEARWELL SKU
- GWP-000023324
- Category
- Servo Systems
Key specifications
- Series
- IS580 electro-hydraulic servo drive
- Voltage class
- T: three-phase 400 V
- Output voltage
- Three-phase 0-480 V (not above input voltage)
- Rated input current
- 89 A
- Encoder type code "R1"
- Resolver
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | INOVANCE IS580T080-R1 IS580 Electro-Hydraulic Servo Drive 45 kW |
|---|---|
| Brand | INOVANCE |
| Model | IS580T080-R1 |
| Category | Servo Systems |
| Series | IS580 electro-hydraulic servo drive |
| Voltage class | T: three-phase 400 V |
| Output voltage | Three-phase 0-480 V (not above input voltage) |
| Rated input current | 89 A |
| Encoder type code "R1" | Resolver |
| Max. output frequency | 300 Hz |
| Rated output current | 91 A |
| Applicable motor capacity | 45 kW |
