IFM IIM216 ifm inductive sensors, M30 x 1.5 threaded (type IIKC012BBSKG/M/US-104) Inductive sensor
- Brand
- IFM
- Model
- IIM216
- GEARWELL SKU
- GWP-000029969
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Connection
- Connector: 1 x M12; contacts gold-plated
- Dimensions
- M30 x 1.5 / L = 70 mm
- Protection
- IP 67; IP 69K
- Sensing range
- 12 mm
- Output function
- normally closed
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM IIM216 ifm inductive sensors, M30 x 1.5 threaded (type IIKC012BBSKG/M/US-104) Inductive sensor |
|---|---|
| Brand | IFM |
| Model | IIM216 |
| Category | Proximity & Photoelectric Sensors |
| Connection | Connector: 1 x M12; contacts gold-plated |
| Dimensions | M30 x 1.5 / L = 70 mm |
| Protection | IP 67; IP 69K |
| Sensing range | 12 mm |
| Output function | normally closed |
| Electrical design | PNP |
| Operating voltage | 10...36 V DC |
| Switching frequency DC | 100 Hz |
