IFM IGS206 ifm inductive sensors, M18 x 1 threaded (type IGB3008BAPKG/US-104) Inductive sensor
- Brand
- IFM
- Model
- IGS206
- GEARWELL SKU
- GWP-000029967
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Connection
- Connector: 1 x M12; coding: A; Contacts: gold-plated
- Dimensions
- M18 x 1 / L = 45 mm
- Protection
- IP 67
- Sensing range
- 8 mm
- Output function
- normally closed
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM IGS206 ifm inductive sensors, M18 x 1 threaded (type IGB3008BAPKG/US-104) Inductive sensor |
|---|---|
| Brand | IFM |
| Model | IGS206 |
| Category | Proximity & Photoelectric Sensors |
| Connection | Connector: 1 x M12; coding: A; Contacts: gold-plated |
| Dimensions | M18 x 1 / L = 45 mm |
| Protection | IP 67 |
| Sensing range | 8 mm |
| Output function | normally closed |
| Electrical design | PNP |
| Operating voltage | 10...30 V DC |
| Switching frequency DC | 400 Hz |
