IFM IG5593 Inductive sensor

Key specifications

EMC: EN 61000-4-2 ESD: 8 kV AD; EN 61000-4-3 HF radiated: 10 V/m; EN 61000-4-4 Burst: 2 kV; EN 61000-4-6 HF conducted: 10 V; EN 55011 emission: class B
MTTF: 1835 years
Cable: 2 m, PUR / PVC; 2 x 0.5 mm²
Weight: 110.8 g
Display: Switching status: 1 x LED, yellow

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	IFM IG5593 Inductive sensor
Brand	IFM
Model	IG5593
Category	Proximity & Photoelectric Sensors
EMC	EN 61000-4-2 ESD: 8 kV AD; EN 61000-4-3 HF radiated: 10 V/m; EN 61000-4-4 Burst: 2 kV; EN 61000-4-6 HF conducted: 10 V; EN 55011 emission: class B
MTTF	1835 years
Cable	2 m, PUR / PVC; 2 x 0.5 mm²
Weight	110.8 g
Display	Switching status: 1 x LED, yellow
Housing	Threaded type
Material	housing: PBT orange; lock nuts: PA 6.6 black
Mounting	flush mountable
Dimensions	M18 x 1 / L = 80 mm
Hysteresis	1...15 % of Sr
Protection	IP 67
Pack quantity	1 pcs.
Sensing range	5 mm
Items supplied	lock nuts: 2
Output function	normally open / closed; (selectable)
Protection class	II
Correction factor	steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.3 / copper: 0.2
Electrical design	PNP/NPN
Operating voltage	10...55 DC V
Operating distance	0...4.05 mm
Switch-point drift	-10...10 % of Sr
Thread designation	M18 x 1
Ambient temperature	-25...80 °C
Max. leakage current	0.8 mA
Overload protection	yes
Minimum load current	4 mA
Real sensing range Sr	5 ± 10 % mm
Switching frequency DC	700 Hz
Short-circuit protection	yes
Reverse polarity protection	yes
Type of short-circuit protection	yes (non-latching)
Max. voltage drop switching output DC	4.6 V
Permanent current rating of switching output DC	400 mA
