IFM IF504A Inductive full-metal sensors Inductive full-metal sensor
- Brand
- IFM
- Model
- IF504A
- GEARWELL SKU
- GWP-000032148
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Threaded type
- Dimensions
- M12 x 1 / L = 60 mm
- Protection
- IP 67; (when used outside the hazardous area: IP 65, IP 67, IP 68, IP 69K)
- Sensing range
- 3 mm
- Output function
- normally closed
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | IFM IF504A Inductive full-metal sensors Inductive full-metal sensor |
|---|---|
| Brand | IFM |
| Model | IF504A |
| Category | Proximity & Photoelectric Sensors |
| Housing | Threaded type |
| Dimensions | M12 x 1 / L = 60 mm |
| Protection | IP 67; (when used outside the hazardous area: IP 65, IP 67, IP 68, IP 69K) |
| Sensing range | 3 mm |
| Output function | normally closed |
| Electrical design | PNP |
| Operating voltage | 10...30 DC V |
| Switching frequency DC | 100 Hz |
