IFM IE5222 Inductive Sensor
- Brand
- IFM
- Model
- IE5222
- GEARWELL SKU
- GWP-000000918
- Category
- Industrial Automation Parts
Key specifications
- Dimensions
- M8 x 1 / L = 50 mm
- Protection
- IP 67
- Product type
- Inductive sensor
- Sensing range
- 1 mm
- Output function
- normally open / closed; (selectable)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm IE5222 (IEA2001-FRKG/PH) is an inductive proximity sensor in an M8 x 1 threaded housing 50 mm long, for flush mounting. Its rated sensing range is 1 mm. The real sensing range is 1 mm ± 10% and the operating distance on steel is 0…0.81 mm. The PNP/NPN switching output is selectable as normally open or normally closed, rated at 200 mA and up to 2000 Hz on 5…36 V DC, with short-circuit protection. On other metals the distance is reduced by ifm's correction factors: 0.7 for stainless steel, 0.4 for brass, 0.3 for aluminum and 0.2 for copper. The sensor has a white-bronze-coated brass housing with a PBT sensing face, connects through a 2 m PUR / PVC cable with 2 x 0.14 mm² conductors and is rated IP67 for -25…80 °C ambient. Two lock nuts are included.
Technical reference
| Product name | IFM IE5222 Inductive Sensor |
|---|---|
| Brand | IFM |
| Model | IE5222 |
| Category | Industrial Automation Parts |
| Dimensions | M8 x 1 / L = 50 mm |
| Protection | IP 67 |
| Product type | Inductive sensor |
| Sensing range | 1 mm |
| Output function | normally open / closed; (selectable) |
| Electrical design | PNP/NPN |
| Operating voltage | 5...36 V DC |
| Ambient temperature | -25...80 °C |
