HYDAC ETS 3226-2-018-000 ETS 3200 Electronic Temperature Switch
- Brand
- HYDAC
- Model
- ETS 3226-2-018-000
- GEARWELL SKU
- GWP-000022615
- Category
- Pressure, Flow & Temperature
Key specifications
- Display
- Yes
- Approvals
- UL approval
- Material number
- 909617
- Switching outputs
- 2
- Temperature probe
- Integrated
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HYDAC ETS 3226-2-018-000 ETS 3200 Electronic Temperature Switch |
|---|---|
| Brand | HYDAC |
| Model | ETS 3226-2-018-000 |
| Category | Pressure, Flow & Temperature |
| Display | Yes |
| Approvals | UL approval |
| Material number | 909617 |
| Switching outputs | 2 |
| Temperature probe | Integrated |
| Temperature range | -25 to 100 |
| Additional interface | No |
| Electrical connection | M12x1, 4-pin |
| Mechanical connection | G1/2 DIN 3852 / external |
| Temperature probe length | 18.0 mm |
