HYDAC DZ5E-01X-250V DZ5E Pressure Sequence Valve Cartridge
- Brand
- HYDAC
- Model
- DZ5E-01X-250V
- GEARWELL SKU
- GWP-000022613
- Category
- Hydraulic Valves
Key specifications
- Pmax
- 350 bar
- Qmax
- 20 l/min
- Cavity
- 06020
- Design
- Cartridge
- Function
- Pressure sequence valve, poppet, direct-acting
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HYDAC DZ5E-01X-250V DZ5E Pressure Sequence Valve Cartridge |
|---|---|
| Brand | HYDAC |
| Model | DZ5E-01X-250V |
| Category | Hydraulic Valves |
| Pmax | 350 bar |
| Qmax | 20 l/min |
| Cavity | 06020 |
| Design | Cartridge |
| Function | Pressure sequence valve, poppet, direct-acting |
| Nominal size | 5 |
| Adjustment type | Tool |
| Material number | 710296 |
| Sealing material | FKM |
| Pressure setting range | 10 - 250 bar |
