Horner HE693THM884M Series 90-30 Thermocouple Input Module
- Brand
- Horner
- Model
- HE693THM884M
- GEARWELL SKU
- GWP-000025715
- Category
- PLCs & I/O
Key specifications
- Channels
- 8
- Brand note
- collected as GE; module manufactured by Horner APG for GE Series 90-30
- Resolution
- 0.1 °C
- Code suffix "M"
- as collected; not listed in the official model-number table
- A/D conversion
- 18-bit integrating, 5 ms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Horner HE693THM884M Series 90-30 Thermocouple Input Module |
|---|---|
| Brand | Horner |
| Model | HE693THM884M |
| Category | PLCs & I/O |
| Channels | 8 |
| Brand note | collected as GE; module manufactured by Horner APG for GE Series 90-30 |
| Resolution | 0.1 °C |
| Code suffix "M" | as collected; not listed in the official model-number table |
| A/D conversion | 18-bit integrating, 5 ms |
| Input impedance | 20 MΩ |
| Power consumption | 100 mA @ 5 VDC |
| Thermocouple types | J, K |
| I/O points required | 8 %AI, 8 %AQ, 16 %I |
| Operating temperature | 0 to 60 °C |
