Horner HE693RTD600 6-Channel RTD Input Module for Series 90-30
- Brand
- Horner
- Model
- HE693RTD600
- GEARWELL SKU
- GWP-000025646
- Category
- PLCs & I/O
Key specifications
- Accuracy
- 0.5 °C typical (1.0 °C for Cu-10 and TD5R)
- Channels
- 6
- Resolution
- 0.5 °C or 0.5 °F
- Update time
- 50 channels per second
- A/D conversion
- 16 bit, integrating
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Horner HE693RTD600 6-Channel RTD Input Module for Series 90-30 |
|---|---|
| Brand | Horner |
| Model | HE693RTD600 |
| Category | PLCs & I/O |
| Accuracy | 0.5 °C typical (1.0 °C for Cu-10 and TD5R) |
| Channels | 6 |
| Resolution | 0.5 °C or 0.5 °F |
| Update time | 50 channels per second |
| A/D conversion | 16 bit, integrating |
| Platform support | Rev R and prior: 90-30 only; later revisions: 90-30 and RX3i |
| Power consumption | 75 mA @ 5 VDC (typical) |
| I/O points required | 6 %AI |
| Supported RTD types | Pt-100E/C/Z, Pt-1000, Ni-120, Cu-10, Cu-50, Cu-53, Cu-100, TD5R, Pt-90 (MIL-7990), linear resistance |
| Operating temperature | 0 to 60 °C |
