HONEYWELL HPMA115C0-003 HPM Series Particulate Matter Sensor
- Brand
- HONEYWELL
- Model
- HPMA115C0-003
- GEARWELL SKU
- GWP-000022426
- Category
- Test & Measurement
Key specifications
- Output data
- PM1.0, PM2.5, PM4.0, PM10
- Size version
- Compact, air inlet and outlet on same side
- Output signal
- UART, 9600 baud
- Response time
- <6 s
- Supply current
- <80 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL HPMA115C0-003 HPM Series Particulate Matter Sensor |
|---|---|
| Brand | HONEYWELL |
| Model | HPMA115C0-003 |
| Category | Test & Measurement |
| Output data | PM1.0, PM2.5, PM4.0, PM10 |
| Size version | Compact, air inlet and outlet on same side |
| Output signal | UART, 9600 baud |
| Response time | <6 s |
| Supply current | <80 mA |
| Supply voltage | 5 +/-0.2 V |
| Concentration range | 0 to 1,000 ug/m3 |
| Operating principle | Laser light scattering |
| Dimensions (L x W x H) | 44 x 36 x 12 mm |
| Operating temperature | -20 to 70 °C |
