HONEYWELL FC-TSAI-1620m Safety Manager Analog Input FTA 16-Ch
- Brand
- HONEYWELL
- Model
- FC-TSAI-1620m
- GEARWELL SKU
- GWP-000025449
- Category
- Terminals, Cables & Connectors
Key specifications
- Evidence
- Honeywell Safety Manager Hardware Reference EP-SM.MAN.6284 R162 (hosted at prod-edam.honeywell.com)
- Approvals
- CE, TUV, UL, CSA, FM
- Seller code
- FC-TSAI-1620M
- Type numbers
- FS-TSAI-1620m / FC-TSAI-1620m
- Input current
- 0-25 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL FC-TSAI-1620m Safety Manager Analog Input FTA 16-Ch |
|---|---|
| Brand | HONEYWELL |
| Model | FC-TSAI-1620m |
| Category | Terminals, Cables & Connectors |
| Evidence | Honeywell Safety Manager Hardware Reference EP-SM.MAN.6284 R162 (hosted at prod-edam.honeywell.com) |
| Approvals | CE, TUV, UL, CSA, FM |
| Seller code | FC-TSAI-1620M |
| Type numbers | FS-TSAI-1620m / FC-TSAI-1620m |
| Input current | 0-25 mA |
| Input resistance | 250 Ω (± 1%) |
| Module dimensions | 210 × 70 × 60 mm (L × W × H) |
| Power requirements | 30 V DC external, 3 mA (without input loop loads) |
| Output to SAI-1620m | 0-4 V DC, accuracy 0.10% |
| Number of input channels | 16 (2 groups of 8 with common 0 V) |
