HONEYWELL CC-PAIH02 Series C High-Level Analog Input Module with HART
- Brand
- HONEYWELL
- Model
- CC-PAIH02
- GEARWELL SKU
- GWP-000025424
- Category
- PLCs & I/O
Key specifications
- Input range
- 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 ohm)
- IOTA models
- CC-TAIX01 / CC-TAIX11, CC-GAIX21 / CC-GAIX11, CC-TAID01 / CC-TAID11
- Input channels
- 16 (12 single-ended / 4 differential)
- Input scan rate
- 50 ms
- Hardware accuracy
- ±0.075% of full scale (23.5 ±2 °C); ±0.15% of full scale (0 to 60 °C)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HONEYWELL CC-PAIH02 Series C High-Level Analog Input Module with HART |
|---|---|
| Brand | HONEYWELL |
| Model | CC-PAIH02 |
| Category | PLCs & I/O |
| Input range | 0 to 5 V, 1 to 5 V, 0.4 to 2 V, 4-20 mA (through 250 ohm) |
| IOTA models | CC-TAIX01 / CC-TAIX11, CC-GAIX21 / CC-GAIX11, CC-TAID01 / CC-TAID11 |
| Input channels | 16 (12 single-ended / 4 differential) |
| Input scan rate | 50 ms |
| Hardware accuracy | ±0.075% of full scale (23.5 ±2 °C); ±0.15% of full scale (0 to 60 °C) |
| Input/output model | CC-PAIH02 - High-Level Analog Input with HART |
| A/D converter resolution | 16 bit |
| Common mode rejection ratio (dc to 60 Hz) | 70 dB |
