HBM T22/100NM T22 Torque Transducer 100 N·m
- Brand
- HBM
- Model
- T22/100NM
- GEARWELL SKU
- GWP-000021751
- Category
- Test & Measurement
Key specifications
- Weight
- 850 g
- Output signal
- ±5 V and 10±8 mA
- Accuracy class
- 0.5
- Collected code
- T22 /100NM (spacing normalized)
- Supply voltage
- 11.5 ... 30 V DC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HBM T22/100NM T22 Torque Transducer 100 N·m |
|---|---|
| Brand | HBM |
| Model | T22/100NM |
| Category | Test & Measurement |
| Weight | 850 g |
| Output signal | ±5 V and 10±8 mA |
| Accuracy class | 0.5 |
| Collected code | T22 /100NM (spacing normalized) |
| Supply voltage | 11.5 ... 30 V DC |
| Degree of protection | IP40 |
| Nominal (rated) torque | 100 N·m |
| Shaft diameter d1 (g6) | 24 mm |
| Nominal (rated) rotational speed | 12000 min-1 |
