GEFRAN F304222 650P-C-RR0-00031-1-G 650 PID Temperature Controller
- Brand
- GEFRAN
- Model
- F304222
- GEARWELL SKU
- GWP-000023117
- Category
- Pressure, Flow & Temperature
Key specifications
- Input
- Universal: thermocouples, resistance thermometers, linear inputs
- Options
- 3 Digital Inputs + RS485
- Output 1
- Analog
- Product ID
- F304222
- Power supply
- 100...240 Vac/dc
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GEFRAN F304222 650P-C-RR0-00031-1-G 650 PID Temperature Controller |
|---|---|
| Brand | GEFRAN |
| Model | F304222 |
| Category | Pressure, Flow & Temperature |
| Input | Universal: thermocouples, resistance thermometers, linear inputs |
| Options | 3 Digital Inputs + RS485 |
| Output 1 | Analog |
| Product ID | F304222 |
| Power supply | 100...240 Vac/dc |
| Outputs 2-3-4 | 2 Relay (5A, 2NO) |
| Sampling time | 60 ms |
| Type designation | 650P-C-RR0-00031-1-G |
| Code as collected | F304222 (seller title: 650P-C-RR0-00031-1-G) |
| Serial communication | RS485 Modbus RTU |
