GEFRAN F021550 TC-K3.5C-C-S TC Load Cell
- Brand
- GEFRAN
- Model
- F021550
- GEARWELL SKU
- GWP-000021364
- Category
- Test & Measurement
Key specifications
- Series
- TC standard size load cell
- Options
- Calibration report included
- Sensitivity
- 2 mV/V
- Series range
- 100 to 20,000 kg
- Accuracy class
- 0.2 %
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GEFRAN F021550 TC-K3.5C-C-S TC Load Cell |
|---|---|
| Brand | GEFRAN |
| Model | F021550 |
| Category | Test & Measurement |
| Series | TC standard size load cell |
| Options | Calibration report included |
| Sensitivity | 2 mV/V |
| Series range | 100 to 20,000 kg |
| Accuracy class | 0.2 % |
| Type designation | TC-K3.5C-C-S 2130X000F00 |
| Measurement range | 0-350 kg |
| Protection degree | IP67 (DIN 40050) |
| Electrical connection | VPT02A10-6PT2 connector |
| Product ID (Gefran order number) | F021550 |
