GE TEC36150 Mag-Break Motor Circuit Protector 3-Pole 150 A
- Brand
- GE
- Model
- TEC36150
- GEARWELL SKU
- GWP-000026262
- Category
- Circuit Protection
Key specifications
- Type
- Standard Capacity Mag-Break motor circuit protector, adjustable magnetic trip, noninterchangeable type TEC
- Poles
- 3
- Evidence
- GE BuyLog catalog page 3-73, Section 3 Molded Case Circuit Breakers, Rev. 1/08 (hosted at assets.usesi.com)
- Approvals
- UL recognized file E-11592; CSA certified LR 40350
- Construction
- complete breaker, includes line and load lugs
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE TEC36150 Mag-Break Motor Circuit Protector 3-Pole 150 A |
|---|---|
| Brand | GE |
| Model | TEC36150 |
| Category | Circuit Protection |
| Type | Standard Capacity Mag-Break motor circuit protector, adjustable magnetic trip, noninterchangeable type TEC |
| Poles | 3 |
| Evidence | GE BuyLog catalog page 3-73, Section 3 Molded Case Circuit Breakers, Rev. 1/08 (hosted at assets.usesi.com) |
| Approvals | UL recognized file E-11592; CSA certified LR 40350 |
| Construction | complete breaker, includes line and load lugs |
| Ampere rating | 150 A |
| Rated voltage | 600 V AC |
| Adjustable trip range | 600-2700 A (AC only) |
| Interrupting rating (TEC complete breaker column) | 10 kAIC at 480 V AC |
