GE MVAJ27L1FB0784D MVAJ 27 Tripping Relay

Key specifications

Case: Size 2 or size 4 case (per type)
Status: Manufacturing of the MVAJ 11 to 34 range discontinued
Supply: High burden relays are for DC operation only
Brand note: MiDOS-range relay originally made by GEC Alstom / ALSTOM / AREVA T&D; now GE Vernova Grid Solutions
Relay type: MVAJ 27

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	GE MVAJ27L1FB0784D MVAJ 27 Tripping Relay
Brand	GE
Model	MVAJ27L1FB0784D
Category	Circuit Protection
Case	Size 2 or size 4 case (per type)
Status	Manufacturing of the MVAJ 11 to 34 range discontinued
Supply	High burden relays are for DC operation only
Brand note	MiDOS-range relay originally made by GEC Alstom / ALSTOM / AREVA T&D; now GE Vernova Grid Solutions
Relay type	MVAJ 27
Burden class	High burden, ESI 48-4 Class EB2
Operating time	Not greater than 10 ms at rated voltage
Reset versions	Hand reset / electrical reset / hand and electrical reset (specify on order)
Order information	Relay type, voltage rating, number and combination of contacts are specified when ordering
Burden at operation	Time-delayed cut-off, 40 to 60 ms
Code suffix "L1FB0784D"	as collected; not listed in an official model-number table (GE brochures give no order-code table; specs depend on the exact model)
Contact rating, break DC	100 W resistive / 50 W inductive, max. 5 A and 660 V
Contact rating, make and carry for 3 s	7500 W DC / 7500 VA AC, max. 30 A and 660 V
