GE MIFIIPI55E10HI00 Multilin MIF II Feeder Protection Relay
- Brand
- GE
- Model
- MIFIIPI55E10HI00
- GEARWELL SKU
- GWP-000026257
- Category
- Circuit Protection
Key specifications
- Curves (I)
- IEC curves
- Options (1)
- Option 1: configurable I/O/LEDs, event recording, oscillography
- Language (E)
- English
- Protocol (0)
- Standard model (Modbus RTU)
- Recloser (0)
- Without recloser
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE MIFIIPI55E10HI00 Multilin MIF II Feeder Protection Relay |
|---|---|
| Brand | GE |
| Model | MIFIIPI55E10HI00 |
| Category | Circuit Protection |
| Curves (I) | IEC curves |
| Options (1) | Option 1: configurable I/O/LEDs, event recording, oscillography |
| Language (E) | English |
| Protocol (0) | Standard model (Modbus RTU) |
| Recloser (0) | Without recloser |
| Application (P) | 3 phase + ground relay |
| Phase range (5) | Phase CT In = 5 A (0.5-12 A) |
| Ground range (5) | Ground CT = 5 A (0.5-12 In) |
| Power supply (HI) | 110-250 Vdc (88-300 Vdc), 110-230 Vac (88-264 Vac) |
| Conformal coating (0) | Without harsh environment conformal coating |
