GE IC698CPE020 PACSystems RX7i 700 MHz CPU with Ethernet
- Brand
- GE
- Model
- IC698CPE020
- GEARWELL SKU
- GWP-000025879
- Category
- PLCs & I/O
Key specifications
- Ethernet
- embedded, two 10/100 Mbps RJ-45 ports (EGD, SRTP, Modbus/TCP)
- Evidence
- GE Intelligent Platforms GFK-2244AG (hosted at qualitrol.com)
- Backplane
- VME64 (ANSI/VITA 1)
- Processor
- 700 MHz Pentium III
- User memory
- 10 MB battery-backed RAM + 10 MB non-volatile flash
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC698CPE020 PACSystems RX7i 700 MHz CPU with Ethernet |
|---|---|
| Brand | GE |
| Model | IC698CPE020 |
| Category | PLCs & I/O |
| Ethernet | embedded, two 10/100 Mbps RJ-45 ports (EGD, SRTP, Modbus/TCP) |
| Evidence | GE Intelligent Platforms GFK-2244AG (hosted at qualitrol.com) |
| Backplane | VME64 (ANSI/VITA 1) |
| Processor | 700 MHz Pentium III |
| User memory | 10 MB battery-backed RAM + 10 MB non-volatile flash |
| Serial ports | RS-485, RS-232 and RS-232 Ethernet station manager port (isolated) |
| Boolean execution | 0.14 ms per 1000 Boolean contacts/coils |
| Power requirements | +5 VDC 4.5 A, +12 VDC 0.042 A, -12 VDC 0.008 A nominal |
| Operating temperature | 0 to 60 C with fan tray (required) |
