GE IC697MDL740 Series 90-70 24/48 VDC 2 A 16-Point Output Module
- Brand
- GE
- Model
- IC697MDL740
- GEARWELL SKU
- GWP-000025870
- Category
- PLCs & I/O
Key specifications
- Outputs
- 16 (four isolated groups of 4)
- Evidence
- GE Fanuc GFK-0086G (hosted at qualitrol.com)
- Isolation
- 1500 V output to backplane; 500 V between groups
- Rated voltage
- 24 or 48 VDC
- Response time
- 2 ms max on / 2 ms max off
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697MDL740 Series 90-70 24/48 VDC 2 A 16-Point Output Module |
|---|---|
| Brand | GE |
| Model | IC697MDL740 |
| Category | PLCs & I/O |
| Outputs | 16 (four isolated groups of 4) |
| Evidence | GE Fanuc GFK-0086G (hosted at qualitrol.com) |
| Isolation | 1500 V output to backplane; 500 V between groups |
| Rated voltage | 24 or 48 VDC |
| Response time | 2 ms max on / 2 ms max off |
| Inrush current | 20 A max for 20 ms |
| Output current | 2 A max per point, 4 A max per group |
| Current from 5 V bus | 0.15 A |
| Output voltage range | 20 to 60 VDC |
