GE IC697HSC700 Series 90-70 High Speed Counter Module
- Brand
- GE
- Model
- IC697HSC700
- GEARWELL SKU
- GWP-000026609
- Category
- PLCs & I/O
Key specifications
- Inputs
- 12 single-ended or differential; TTL 5 VDC, non-TTL 10-30 VDC, magnetic pickup 400 mV (I1-I4)
- Outputs
- 4 positive logic (source), optically isolated, 1.0 A each at 10-30 VDC
- Evidence
- GE Fanuc GFK-1057D (hosted at qualitrol.com)
- Isolation
- 1500 V peak (1 s); 30 V AC/DC steady state
- Counter types
- 5 selectable (Types A-E)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC697HSC700 Series 90-70 High Speed Counter Module |
|---|---|
| Brand | GE |
| Model | IC697HSC700 |
| Category | PLCs & I/O |
| Inputs | 12 single-ended or differential; TTL 5 VDC, non-TTL 10-30 VDC, magnetic pickup 400 mV (I1-I4) |
| Outputs | 4 positive logic (source), optically isolated, 1.0 A each at 10-30 VDC |
| Evidence | GE Fanuc GFK-1057D (hosted at qualitrol.com) |
| Isolation | 1500 V peak (1 s); 30 V AC/DC steady state |
| Counter types | 5 selectable (Types A-E) |
| Encoder power | 5 VDC, 500 mA at 40 C |
| Module current | 1 A + 10 mA per ON output + 1.6 x encoder current (5 VDC backplane) |
| Output protection | 5 A fuse common to all outputs |
| Maximum count rate | 200 kHz; 800 kHz Type E in A Quad B mode |
