GE IC697CPX782-CD Series 90-70 96 MHz CPU 1 MB

Key specifications

Evidence: GE Fanuc GFK-1431F (hosted at qualitrol.com)
Processor: 96 MHz 80486DX4, 32-bit, floating point
I/O capacity: 12K inputs and outputs (any mix), up to 8K analog I/O
Serial ports: Port 1 RS-232; Port 2 RS-485 (optocoupler isolated); Port 3 RS-485 (not isolated); SNP Slave
Code suffix "CD": as collected; GE catalog-number version/revision suffix on base IC697CPX782 (GE documents use letter suffixes for hardware/firmware versions); not listed separately in the official model table

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	GE IC697CPX782-CD Series 90-70 96 MHz CPU 1 MB
Brand	GE
Model	IC697CPX782-CD
Category	PLCs & I/O
Evidence	GE Fanuc GFK-1431F (hosted at qualitrol.com)
Processor	96 MHz 80486DX4, 32-bit, floating point
I/O capacity	12K inputs and outputs (any mix), up to 8K analog I/O
Serial ports	Port 1 RS-232; Port 2 RS-485 (optocoupler isolated); Port 3 RS-485 (not isolated); SNP Slave
Code suffix "CD"	as collected; GE catalog-number version/revision suffix on base IC697CPX782 (GE documents use letter suffixes for hardware/firmware versions); not listed separately in the official model table
Boolean execution	0.4 microseconds per boolean function
User flash memory	256K non-volatile
Current from 5 V bus	3.1 A nominal
Operating temperature	0 to 60 C
Battery-backed user memory	1 Mbyte
