GE IC695PNC001 PACSystems RX3i PROFINET Controller Module
- Brand
- GE
- Model
- IC695PNC001
- GEARWELL SKU
- GWP-000026602
- Category
- Industrial Communication
Key specifications
- Ports
- 2 x RJ-45 10/100/1000 Mbps copper, 2 x SFP cages (SFP devices ordered separately)
- Evidence
- Emerson/GE GFK-2573X PACSystems RX3i PROFINET Controller IC695PNC001 Important Product Information (hosted at download.astor.com.pl)
- I/O memory
- 128 Kbytes combined input/output per controller
- Update rates
- 1 to 512 ms configurable
- Catalog number
- IC695PNC001
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC695PNC001 PACSystems RX3i PROFINET Controller Module |
|---|---|
| Brand | GE |
| Model | IC695PNC001 |
| Category | Industrial Communication |
| Ports | 2 x RJ-45 10/100/1000 Mbps copper, 2 x SFP cages (SFP devices ordered separately) |
| Evidence | Emerson/GE GFK-2573X PACSystems RX3i PROFINET Controller IC695PNC001 Important Product Information (hosted at download.astor.com.pl) |
| I/O memory | 128 Kbytes combined input/output per controller |
| Update rates | 1 to 512 ms configurable |
| Catalog number | IC695PNC001 |
| PROFINET support | PROFINET v2.2 General Class A I/O-Controller; redundancy per PROFINET v2.3 Type S-2 |
| Operating temperature | PNC001-Ax: 0 to 60 C; PNC001-Bxxx: -25 to 60 C |
| Controllers per RX3i CPU | 4 (main rack only) |
| I/O-Devices per controller | 128 |
