GE IC695CRU320-EN PACSystems RX3i Redundancy CPU Module
- Brand
- GE
- Model
- IC695CRU320-EN
- GEARWELL SKU
- GWP-000025819
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE GFK-2514AA PACSystems RX3i Redundancy CPU Important Product Information (hosted at qualitrol.com)
- Description
- RX3i 1 GHz Celeron M CPU with 64 MB user memory (hot standby redundancy)
- Catalog number
- IC695CRU320
- Program storage
- up to 64 MB battery-backed RAM; 64 MB non-volatile flash
- Revision suffix
- -EN (as collected; hardware/firmware revision, not part of the catalog number)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC695CRU320-EN PACSystems RX3i Redundancy CPU Module |
|---|---|
| Brand | GE |
| Model | IC695CRU320-EN |
| Category | PLCs & I/O |
| Evidence | GE GFK-2514AA PACSystems RX3i Redundancy CPU Important Product Information (hosted at qualitrol.com) |
| Description | RX3i 1 GHz Celeron M CPU with 64 MB user memory (hot standby redundancy) |
| Catalog number | IC695CRU320 |
| Program storage | up to 64 MB battery-backed RAM; 64 MB non-volatile flash |
| Revision suffix | -EN (as collected; hardware/firmware revision, not part of the catalog number) |
| Switchover time | max. 1 logic scan, min. 3.133 ms |
| Redundancy links | up to two IC695RMX128/228 synchronization links |
| Power requirements | +3.3 Vdc: 1.0 A nominal; +5 Vdc: 1.2 A nominal |
| Operating temperature | 0 to 60 °C |
| Embedded communications | RS-232, RS-485 (Modbus RTU slave, SNP, Serial I/O) |
