GE IC695ALG616 PACSystems RX3i 16-Channel Analog Input Module
- Brand
- GE
- Model
- IC695ALG616
- GEARWELL SKU
- GWP-000025805
- Category
- PLCs & I/O
Key specifications
- Channels
- 16 single-ended or 8 differential
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 9.9
- Catalog number
- IC695ALG616
- Current ranges
- 0 to 20 mA, 4 to 20 mA, +/-20 mA
- Filter options
- 8, 12, 16, 40, 200, 500 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC695ALG616 PACSystems RX3i 16-Channel Analog Input Module |
|---|---|
| Brand | GE |
| Model | IC695ALG616 |
| Category | PLCs & I/O |
| Channels | 16 single-ended or 8 differential |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 9.9 |
| Catalog number | IC695ALG616 |
| Current ranges | 0 to 20 mA, 4 to 20 mA, +/-20 mA |
| Filter options | 8, 12, 16, 40, 200, 500 Hz |
| Voltage ranges | +/-10 V, 0 to 10 V, +/-5 V, 0 to 5 V, 1 to 5 V |
| Input impedance | >100 kOhm voltage; 249 Ohm current |
| Backplane power (-FB and later) | 350 mA max at 5 V, 200 mA max at 3.3 V |
