GE IC693ALG392 Series 90-30 8-Channel Analog Current/Voltage Output
- Brand
- GE
- Model
- IC693ALG392
- GEARWELL SKU
- GWP-000025727
- Category
- PLCs & I/O
Key specifications
- Channels
- 1 to 8 selectable, single-ended
- Resolution
- 15 to 16 bits depending on range (0.5 uA at 4-20 mA)
- Diagnostics
- open-wire fault per channel in current modes
- Update rate
- 8 ms approx. (all eight channels)
- Output ranges
- 0-10 V, -10 to +10 V, 0-20 mA, 4-20 mA (per channel)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693ALG392 Series 90-30 8-Channel Analog Current/Voltage Output |
|---|---|
| Brand | GE |
| Model | IC693ALG392 |
| Category | PLCs & I/O |
| Channels | 1 to 8 selectable, single-ended |
| Resolution | 15 to 16 bits depending on range (0.5 uA at 4-20 mA) |
| Diagnostics | open-wire fault per channel in current modes |
| Update rate | 8 ms approx. (all eight channels) |
| Output ranges | 0-10 V, -10 to +10 V, 0-20 mA, 4-20 mA (per channel) |
| User supply voltage | +24 VDC nominal, 20-30 VDC |
