GE IC693ALG390 Series 90-30 2-Channel Analog Voltage Output Module
- Brand
- GE
- Model
- IC693ALG390
- GEARWELL SKU
- GWP-000025726
- Category
- PLCs & I/O
Key specifications
- Channels
- 2
- Isolation
- 1500 V field side to logic side
- Resolution
- 12 bits plus sign (2.5 mV per LSB)
- Update rate
- about 5 ms (both channels)
- Voltage range
- -10 to +10 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693ALG390 Series 90-30 2-Channel Analog Voltage Output Module |
|---|---|
| Brand | GE |
| Model | IC693ALG390 |
| Category | PLCs & I/O |
| Channels | 2 |
| Isolation | 1500 V field side to logic side |
| Resolution | 12 bits plus sign (2.5 mV per LSB) |
| Update rate | about 5 ms (both channels) |
| Voltage range | -10 to +10 V |
| Output loading | 5 mA max (2 kohm minimum) |
| Absolute accuracy | +/-5 mV at 25 C |
| External supply voltage range | 18-30 VDC |
