GE IC693ALG220G Series 90-30 4-Channel Analog Voltage Input Module
- Brand
- GE
- Model
- IC693ALG220G
- GEARWELL SKU
- GWP-000025723
- Category
- PLCs & I/O
Key specifications
- Channels
- 4
- Isolation
- 1500 V field side to logic side
- Resolution
- 12 bits (5 mV/20 uA per LSB)
- Update rate
- 4 ms (all four channels)
- Code suffix "G"
- as collected; GE catalog-number version suffix on base IC693ALG220 (GE documents use letter suffixes for hardware versions); not listed separately in the official model table
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693ALG220G Series 90-30 4-Channel Analog Voltage Input Module |
|---|---|
| Brand | GE |
| Model | IC693ALG220G |
| Category | PLCs & I/O |
| Channels | 4 |
| Isolation | 1500 V field side to logic side |
| Resolution | 12 bits (5 mV/20 uA per LSB) |
| Update rate | 4 ms (all four channels) |
| Code suffix "G" | as collected; GE catalog-number version suffix on base IC693ALG220 (GE documents use letter suffixes for hardware versions); not listed separately in the official model table |
| Voltage range | -10 to +10 V |
| Input impedance | > 9 Mohm (voltage mode), 250 ohm (current mode) |
| Current input mode | limited, via 250 ohm shunt jumper (4-20 mA = 1-5 V) |
| Internal power consumption | 27 mA @ +5 V, 98 mA @ isolated +24 V |
