GE IC690ACC901 Series 90 RS-422 (SNP) to RS-232 Miniconverter Kit
- Brand
- GE
- Model
- IC690ACC901
- GEARWELL SKU
- GWP-000025722
- Category
- Industrial Communication
Key specifications
- Baud rate
- 38.4 kbaud maximum
- Kit contents
- RS-422 (SNP) to RS-232 miniconverter, 6 ft (2 m) serial extension cable, 9-pin to 25-pin converter plug
- PLC connector
- 15-pin D-shell male (RS-422 / SNP)
- Supply voltage
- +5 VDC (from PLC power supply)
- Typical current
- 150 mA (version A), 100 mA (version B)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC690ACC901 Series 90 RS-422 (SNP) to RS-232 Miniconverter Kit |
|---|---|
| Brand | GE |
| Model | IC690ACC901 |
| Category | Industrial Communication |
| Baud rate | 38.4 kbaud maximum |
| Kit contents | RS-422 (SNP) to RS-232 miniconverter, 6 ft (2 m) serial extension cable, 9-pin to 25-pin converter plug |
| PLC connector | 15-pin D-shell male (RS-422 / SNP) |
| Supply voltage | +5 VDC (from PLC power supply) |
| Typical current | 150 mA (version A), 100 mA (version B) |
| Ground isolation | not provided |
| RS-232 connector | 9-pin D-shell male |
| Operating temperature | 0 to 70 C |
