GE IC670CHS001 Field Control I/O Terminal Block, Barrier Terminals
- Brand
- GE
- Model
- IC670CHS001
- GEARWELL SKU
- GWP-000025716
- Category
- PLCs & I/O
Key specifications
- Grounding
- metal grounding strip (IC670CHS001B or later); use grounded conductive DIN rail
- Terminals
- 37
- Product type
- I/O Terminal Block with Barrier Terminals
- Wire range per terminal
- up to two AWG #14 (2.1 mm2) to AWG #22 (0.35 mm2) wires
- Modules per terminal block
- 2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC670CHS001 Field Control I/O Terminal Block, Barrier Terminals |
|---|---|
| Brand | GE |
| Model | IC670CHS001 |
| Category | PLCs & I/O |
| Grounding | metal grounding strip (IC670CHS001B or later); use grounded conductive DIN rail |
| Terminals | 37 |
| Product type | I/O Terminal Block with Barrier Terminals |
| Wire range per terminal | up to two AWG #14 (2.1 mm2) to AWG #22 (0.35 mm2) wires |
| Modules per terminal block | 2 |
| Recommended terminal torque | 8 (7-9) in-lb |
