GE IC610MDL179A Series One 115/230VAC 8-Circuit Output Module
- Brand
- GE
- Model
- IC610MDL179A
- GEARWELL SKU
- GWP-000025705
- Category
- PLCs & I/O
Key specifications
- Weight
- 210 g
- Evidence
- GE Series One Programmable Controller manual GEK-90842 excerpt (hosted at qualitrol.com)
- AC frequency
- 47-63 Hz
- Code suffix "A"
- as collected; revision suffix, not listed in the official catalog number table
- Output points
- 8
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC610MDL179A Series One 115/230VAC 8-Circuit Output Module |
|---|---|
| Brand | GE |
| Model | IC610MDL179A |
| Category | PLCs & I/O |
| Weight | 210 g |
| Evidence | GE Series One Programmable Controller manual GEK-90842 excerpt (hosted at qualitrol.com) |
| AC frequency | 47-63 Hz |
| Code suffix "A" | as collected; revision suffix, not listed in the official catalog number table |
| Output points | 8 |
| Fuses (internal) | (2) 5 A, one per group of 4 |
| Maximum inrush | 10 A for 17 ms |
| Terminal board | Removable |
| Operating voltage | 80-264 VAC |
| Maximum current per circuit | 1 A |
