GE IC610MDL129A Series One 115VAC 16-Circuit Input Module

Key specifications

Evidence: GE Series One Programmable Controller manual GEK-90842 excerpt (hosted at qualitrol.com)
Grouping: 2 groups of 8 circuits
ON level: above 80 V
OFF level: below 15 V
AC frequency: 47-63 Hz

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	GE IC610MDL129A Series One 115VAC 16-Circuit Input Module
Brand	GE
Model	IC610MDL129A
Category	PLCs & I/O
Evidence	GE Series One Programmable Controller manual GEK-90842 excerpt (hosted at qualitrol.com)
Grouping	2 groups of 8 circuits
ON level	above 80 V
OFF level	below 15 V
AC frequency	47-63 Hz
Input points	16
Code suffix "A"	as collected; revision suffix, not listed in the official catalog number table
Terminal board	Removable
Operating voltage	80-132 VAC
