GE IC200MDL241 VersaMax 240VAC 16-Point Input Module
- Brand
- GE
- Model
- IC200MDL241
- GEARWELL SKU
- GWP-000026541
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE Fanuc GFK-2464B (hosted at qualitrol.com)
- Isolation
- 250 VAC continuous, 1500 VAC for 1 minute (user input to logic and group to group)
- Module ID
- 88048804
- Input voltage
- 0 to 264 VAC (47 to 63 Hz), 240 VAC nominal
- Number of inputs
- 16 (2 groups of 8)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC200MDL241 VersaMax 240VAC 16-Point Input Module |
|---|---|
| Brand | GE |
| Model | IC200MDL241 |
| Category | PLCs & I/O |
| Evidence | GE Fanuc GFK-2464B (hosted at qualitrol.com) |
| Isolation | 250 VAC continuous, 1500 VAC for 1 minute (user input to logic and group to group) |
| Module ID | 88048804 |
| Input voltage | 0 to 264 VAC (47 to 63 Hz), 240 VAC nominal |
| Number of inputs | 16 (2 groups of 8) |
| On-state voltage | 155 to 264 VAC |
| Off-state voltage | 0 to 40 VAC |
| Backplane current consumption | 110 mA max. (5 V) |
