GE IC200ALG264 VersaMax 15-Channel Current Analog Input Module
- Brand
- GE
- Model
- IC200ALG264
- GEARWELL SKU
- GWP-000025647
- Category
- PLCs & I/O
Key specifications
- Channels
- 15 single-ended, one group
- Evidence
- Emerson GFK-1935H (hosted at download.astor.com.pl); GFK-1504K
- Isolation
- 250 VAC continuous; 1500 VAC for 1 minute
- Resolution
- 15 bits (0.5 µA/count at 4-20 mA)
- Input range
- 4-20 mA (default) or 0-20 mA (jumper)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC200ALG264 VersaMax 15-Channel Current Analog Input Module |
|---|---|
| Brand | GE |
| Model | IC200ALG264 |
| Category | PLCs & I/O |
| Channels | 15 single-ended, one group |
| Evidence | Emerson GFK-1935H (hosted at download.astor.com.pl); GFK-1504K |
| Isolation | 250 VAC continuous; 1500 VAC for 1 minute |
| Resolution | 15 bits (0.5 µA/count at 4-20 mA) |
| Input range | 4-20 mA (default) or 0-20 mA (jumper) |
| Update rate | 7.5 ms |
| Input impedance | 100 Ω |
| Accuracy at 25 °C | ±0.3% typical, ±0.5% max of full scale |
| Backplane current | 100 mA max at 5 V |
