GE F650-N-F-L-F-2-G-1-HI-P-6E Multilin F650 Feeder Protection Relay
- Brand
- GE
- Model
- F650-N-F-L-F-2-G-1-HI-P-6E
- GEARWELL SKU
- GWP-000025638
- Category
- Circuit Protection
Key specifications
- Display (N)
- Graphic display with IEC symbols
- Language (P)
- Russian/English
- Protocol (6)
- IEC 61850 Edition 2, Modbus RTU & TCP/IP, DNP 3.0 Level 2, IEC 60870-5-104
- Enhanced display (E)
- Enhanced display with front USB port
- Auxiliary voltage (HI)
- 110-250 Vdc (88-300), 120-230 Vac (96-250)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE F650-N-F-L-F-2-G-1-HI-P-6E Multilin F650 Feeder Protection Relay |
|---|---|
| Brand | GE |
| Model | F650-N-F-L-F-2-G-1-HI-P-6E |
| Category | Circuit Protection |
| Display (N) | Graphic display with IEC symbols |
| Language (P) | Russian/English |
| Protocol (6) | IEC 61850 Edition 2, Modbus RTU & TCP/IP, DNP 3.0 Level 2, IEC 60870-5-104 |
| Enhanced display (E) | Enhanced display with front USB port |
| Auxiliary voltage (HI) | 110-250 Vdc (88-300), 120-230 Vac (96-250) |
| I/O board in slot F (2) | 8 digital inputs + 8 outputs + 2 trip/close circuit supervision circuits |
| I/O board in slot G (1) | 16 digital inputs + 8 outputs |
| Environmental protection | Without harsh environment conformal coating (position blank) |
| Rear serial communications board 1 (F) | None |
| Rear Ethernet communications board 2 (L) | PRP, 1588, 10/100 Base TX + redundant 100 Base TX |
