GE 8811-IO-DC PAC8000 SafetyNet 24 VDC Discrete I/O Module
- Brand
- GE
- Model
- 8811-IO-DC
- GEARWELL SKU
- GWP-000025588
- Category
- PLCs & I/O
Key specifications
- Channels
- 8, independently configured as inputs or outputs
- Evidence
- GE Automation & Control 'PAC8000 SafetyNet' datasheet section 5 (www.geautomation.com, hosted at core.instrumart.com)
- Seller code
- 8811-IO-DC 8811-IO-DC-01 (as collected; '-01' suffix not listed in the official datasheet)
- Hazardous area
- EEx nA nL IIC T4; Class 1 Div. 2 Grps A,B,C,D T4
- Input response time
- 5 ms max (input change to Railbus)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE 8811-IO-DC PAC8000 SafetyNet 24 VDC Discrete I/O Module |
|---|---|
| Brand | GE |
| Model | 8811-IO-DC |
| Category | PLCs & I/O |
| Channels | 8, independently configured as inputs or outputs |
| Evidence | GE Automation & Control 'PAC8000 SafetyNet' datasheet section 5 (www.geautomation.com, hosted at core.instrumart.com) |
| Seller code | 8811-IO-DC 8811-IO-DC-01 (as collected; '-01' suffix not listed in the official datasheet) |
| Hazardous area | EEx nA nL IIC T4; Class 1 Div. 2 Grps A,B,C,D T4 |
| Input response time | 5 ms max (input change to Railbus) |
| Safety certification | SIL 2 (SafetyNet IO modules) |
| Isolation (channel to Railbus) | 250 VAC |
| Max output current per channel | 2 A |
| Max output current per module (continuous) | 6 A |
