GE 489-P5-LO-A20-E Multilin 489 Generator Protection Relay
- Brand
- GE
- Model
- 489-P5-LO-A20-E
- GEARWELL SKU
- GWP-000026208
- Category
- Machine Safety & Vision
Key specifications
- Evidence
- GE Vernova Multilin 489 brochure GEA-12947 (ordering table)
- Order code
- 489-P5-LO-A20-E (collected with 'SR' prefix)
- RTD inputs
- 12, field programmable (platinum, nickel or copper)
- Seller code
- SR489-P5-LO-A20-E (GE names the product SR489; official order code is written 489-...)
- Enhancement (E)
- Enhanced display, larger LCD, improved keypad
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE 489-P5-LO-A20-E Multilin 489 Generator Protection Relay |
|---|---|
| Brand | GE |
| Model | 489-P5-LO-A20-E |
| Category | Machine Safety & Vision |
| Evidence | GE Vernova Multilin 489 brochure GEA-12947 (ordering table) |
| Order code | 489-P5-LO-A20-E (collected with 'SR' prefix) |
| RTD inputs | 12, field programmable (platinum, nickel or copper) |
| Seller code | SR489-P5-LO-A20-E (GE names the product SR489; official order code is written 489-...) |
| Enhancement (E) | Enhanced display, larger LCD, improved keypad |
| Output relays | 6 electromechanical Form C, trip duty |
| Digital inputs | 9 opto-isolated (7 assignable) |
| Control power (LO) | 20-60 V DC; 20-48 V AC at 48-62 Hz (ordering table: 24-60 V DC) |
| Analog outputs (A20) | 4-20 mA |
| Phase current inputs (P5) | 5 A phase CT secondaries |
