GE 369-HI-0-0-0-0-0-E Multilin 369 Motor Protection Relay

Key specifications

Series: Multilin 369 Motor Protection System
Evidence: GE 369 brochure order-code table; exact code also listed by AX Control
Metering: No metering or backspin detection (0)
Order code: 369-HI-0-0-0-0-0-E
RTD inputs: No optional RTD inputs (0)

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	GE 369-HI-0-0-0-0-0-E Multilin 369 Motor Protection Relay
Brand	GE
Model	369-HI-0-0-0-0-0-E
Category	Machine Safety & Vision
Series	Multilin 369 Motor Protection System
Evidence	GE 369 brochure order-code table; exact code also listed by AX Control
Metering	No metering or backspin detection (0)
Order code	369-HI-0-0-0-0-0-E
RTD inputs	No optional RTD inputs (0)
Control power	50-300 VDC / 40-265 VAC (HI)
Fiber optic port	No fiber optic port (0)
Protocol interface	No optional protocol interface (0)
Diagnostics / faceplate	Enhanced diagnostics and enhanced faceplate (E)
Harsh environment option	Not fitted (0)
