Fuji Electric PUMATEE1-0BY00 PUM Multi-loop Temperature Control Module
- Brand
- Fuji Electric
- Model
- PUMATEE1-0BY00
- GEARWELL SKU
- GWP-000022553
- Category
- Pressure, Flow & Temperature
Key specifications
- Sampling
- 100 ms (200 ms for resistance bulb and thermocouple types)
- Data sheet
- EDS11-165c
- Power supply
- 24 V DC ±10%
- Option 1 (digit 11 = Y)
- Not fitted
- Input type (digit 5 = T)
- Thermocouple / resistance bulb (all channels)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Fuji Electric PUMATEE1-0BY00 PUM Multi-loop Temperature Control Module |
|---|---|
| Brand | Fuji Electric |
| Model | PUMATEE1-0BY00 |
| Category | Pressure, Flow & Temperature |
| Sampling | 100 ms (200 ms for resistance bulb and thermocouple types) |
| Data sheet | EDS11-165c |
| Power supply | 24 V DC ±10% |
| Option 1 (digit 11 = Y) | Not fitted |
| Input type (digit 5 = T) | Thermocouple / resistance bulb (all channels) |
| Module type (digit 4 = A) | 4ch control module |
| Input measurement accuracy | ±0.3%FS |
| Operation manual (digit 10 = B) | English |
| OUT1, 2 output type (digit 6 = E) | Current output |
| OUT3, 4 output type (digit 7 = E) | Current output |
