FOTEK MT-72R-CDS MT Series PID+Fuzzy Temperature Controller
- Brand
- FOTEK
- Model
- MT-72R-CDS
- GEARWELL SKU
- GWP-000021100
- Category
- Pressure, Flow & Temperature
Key specifications
- Outline
- 72x72 mm
- Base type
- MT72-R
- Alarm output
- 3 A / 250 VAC SPDT
- Power supply
- 90~265 VAC 50/60 Hz, 5 VA max.
- Sensor input
- K / J / PT-100 selectable
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FOTEK MT-72R-CDS MT Series PID+Fuzzy Temperature Controller |
|---|---|
| Brand | FOTEK |
| Model | MT-72R-CDS |
| Category | Pressure, Flow & Temperature |
| Outline | 72x72 mm |
| Base type | MT72-R |
| Alarm output | 3 A / 250 VAC SPDT |
| Power supply | 90~265 VAC 50/60 Hz, 5 VA max. |
| Sensor input | K / J / PT-100 selectable |
| Control method | Fuzzy + PID or ON/OFF settable |
| Control output | Relay 3 A/250 VAC SPDT |
| Code suffix "CDS" | as collected; not listed in the official model-number table |
| Display accuracy | ±0.1% of FS + 1 digit |
| Operating ambient | -20 ~ +75 °C, 25 ~ 85% RH |
