FESTO HPV-22-30-A HPV Feed Separator
- Brand
- FESTO
- Model
- HPV-22-30-A
- GEARWELL SKU
- GWP-000022743
- Category
- Cylinders & Actuators
Key specifications
- Stroke
- 30 mm
- Evidence
- Festo SE & Co. KG data sheet 529353 (hosted at landefeld.com)
- Cycle time
- 304.8 ms
- Part number
- 529353
- Product weight
- 950 g
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO HPV-22-30-A HPV Feed Separator |
|---|---|
| Brand | FESTO |
| Model | HPV-22-30-A |
| Category | Cylinders & Actuators |
| Stroke | 30 mm |
| Evidence | Festo SE & Co. KG data sheet 529353 (hosted at landefeld.com) |
| Cycle time | 304.8 ms |
| Part number | 529353 |
| Product weight | 950 g |
| Piston diameter | 22 mm |
| Mode of operation | Double-acting, twin piston |
| Operating pressure | 3 ... 8 bar |
| Pneumatic connection | M5 |
| Theoretical force at 6 bar, advance | 225 N |
