FESTO 6758 TH-3-M5 Finger Lever Valve
- Brand
- FESTO
- Model
- 6758
- GEARWELL SKU
- GWP-000023668
- Category
- Valves & Manifolds
Key specifications
- Part number
- 6758
- Nominal width
- 2 mm
- Valve function
- 3/2-way, closed, monostable
- Type designation
- TH-3-M5
- Operating pressure
- -0.95 ... 8 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | FESTO 6758 TH-3-M5 Finger Lever Valve |
|---|---|
| Brand | FESTO |
| Model | 6758 |
| Category | Valves & Manifolds |
| Part number | 6758 |
| Nominal width | 2 mm |
| Valve function | 3/2-way, closed, monostable |
| Type designation | TH-3-M5 |
| Operating pressure | -0.95 ... 8 bar |
| Ambient temperature | -10 ... 60 °C |
| Pneumatic connection 1 | M5 |
| Pneumatic connection 2 | M5 |
| Pneumatic working port | M5 |
| Normal nominal flow rate (normalized to DIN 1343) | 80 l/min |
