EMERSON MMS6110 epro MMS 6000 Dual Channel Shaft Vibration Monitor
- Brand
- EMERSON
- Model
- MMS6110
- GEARWELL SKU
- GWP-000025106
- Category
- Test & Measurement
Key specifications
- Format
- PCB/Euro card, DIN 41494 (100 x 160 mm), width 30 mm (6 TE), height 128.4 mm (3 HE)
- Evidence
- epro data sheet 6010-00001 01/03 (manufacturer original, hosted at profess.cz)
- Order number
- 9100-00001
- Product line
- epro MMS 6000 (now Emerson AMS 6500 family)
- Sensor inputs
- 2 differential inputs for eddy-current sensors, input resistance >100 kOhm, 0 ... -22 V dc
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | EMERSON MMS6110 epro MMS 6000 Dual Channel Shaft Vibration Monitor |
|---|---|
| Brand | EMERSON |
| Model | MMS6110 |
| Category | Test & Measurement |
| Format | PCB/Euro card, DIN 41494 (100 x 160 mm), width 30 mm (6 TE), height 128.4 mm (3 HE) |
| Evidence | epro data sheet 6010-00001 01/03 (manufacturer original, hosted at profess.cz) |
| Order number | 9100-00001 |
| Product line | epro MMS 6000 (now Emerson AMS 6500 family) |
| Sensor inputs | 2 differential inputs for eddy-current sensors, input resistance >100 kOhm, 0 ... -22 V dc |
| Supply voltage | 18 ... 24 ... 31.2 (redundant inputs, IEC 654-2 class DC4) V DC |
| Measuring range | 0 ... 400 mV (smallest) to 0 ... 8000 mV (largest) |
| Power consumption | max. 6 W (max. 250 mA at 24 V) |
| Input frequency range | 1/5 ... 50 ... 2000 Hz |
| Operating temperature | 0 ... +65 °C |
